Model-506 277V
SKU: 4046310
In Stock

Specifications
@ 80 F | 60% RH | |||
Water Removal
500 Pints/Day | Efficiency
9.2 Pints/kWh | Energy Factor
4.4 L/kWh | Current Draw
8.2 Amps |
Power
2,250 W | BTU (Total)
30,500 | BTU (Heat of Condensation)
22,800 | BTU (Motor Load)
7,700 |
@ 75 F | 50% RH | |||
Water Removal
320 Pints/Day | Efficiency
6.8 Pints/kWh | Energy Factor
3.2 L/kWh | Current Draw
7.9 Amps |
CALIFORNIA TITLE 24 COMPLIANT | |||
Non-Ducted Energy Factor
6.7 Pints/kWh @ 65 F / 60% RH | Ducted Energy Factor
7.9 Pints/kWh @ 73 F / 60% RH | ||
Part Number
4046310 | Dehumidifier Type
Refrigerant Dehumidifier | CFM
1,150 @ 0.0" WG | Operating Temperature
56 F Min - 95 F Max |
Supply Voltage
277V | Unit Dimensions
44.8" L x 28.9 " W x 27.4" H | Unit Weight
275 lb | Control Type
Onboard Digital Controls with Low Voltage Terminal Block |
Air Filter MERV Rating
MERV 13 | Air Filter Dimensions
18" x 20" x 2" | Power Cord
NEMA L7-20P | Refrigerant Type
R454B |
Refrigerant Amount
3 lb 14 oz | Drain Port Connection
3/4" Threaded NPT | Warranty
5 Years Limited |
