Model - 506 277V
SKU: 4046310
In Stock
MSRP price:
$99,999.50 / 10 items
Specifications
@ 80 F | 60% RH | |||
| Water RemovalWater Removal 500 Pints/Day | EfficiencyEfficiency 9.2 Pints/kWh | Energy FactorEnergy Factor 4.4 L/kWh | PowerPower 2,250 W |
| Current DrawCurrent Draw 8.2 Amps | BTU (Total)BTU (Total) 30,500 | BTU (Heat of Condensation)BTU (Heat of Condensation) 22,800 | BTU (Motor Load)BTU (Motor Load) 7,700 |
@ 75 F | 50% RH | |||
| Water RemovalWater Removal 320 Pints/Day | EfficiencyEfficiency 6.8 Pints/kWh | Energy FactorEnergy Factor 3.2 L/kWh | Current DrawCurrent Draw 7.9 Amps |
CALIFORNIA TITLE 24 COMPLIANT | |||
| Non-Ducted Energy FactorNon-Ducted Energy Factor 6.7 Pints/kWh @ 65 F / 60% RH | Ducted Energy FactorDucted Energy Factor 7.9 Pints/kWh @ 73 F / 60% RH | ||
| Part NumberPart Number 4046310 | Dehumidifier TypeDehumidifier Type Refrigerant Dehumidifier | CFMCFM 1,150 @ 0.0" WG | Operating TemperatureOperating Temperature 56 F Min - 95 F Max |
| Supply VoltageSupply Voltage 277V, 60 Hz | Unit DimensionsUnit Dimensions 44.8" L x 28.9 " W x 27.4" H | Unit WeightUnit Weight 275 lb | Control TypeControl Type Onboard Digital Controls with Low Voltage Terminal Block |
| Air Filter MERV RatingAir Filter MERV Rating MERV 13 | Air Filter DimensionsAir Filter Dimensions 18" x 20" x 2" | Power CordPower Cord NEMA L7-20P | Refrigerant TypeRefrigerant Type R454B |
| Refrigerant AmountRefrigerant Amount 3 lb 14 oz | Drain Port ConnectionDrain Port Connection 3/4" Threaded NPT | WarrantyWarranty 5 Years Limited | |
